ENGINE
Type | rear, transverse, 90 degree V8 |
Bore/Stroke | 66.8 X 71 mm |
Unitary Displacement | 248.83 cc |
Total Displacement | 1990.64 cc |
Compression ratio | 9 : 1 |
Maximum power | 114 KW (115 hp) at 6800 rpm |
Power Per Litre | 78 CV/l |
Maximum Torque | 170 Nm (17.3 kgm) at 4200 rpm |
Valve Actutation | Twin overhead camshafts per bank, two valves per cylinder |
Fuel feed | four weber 34 DCNF carburettors |
Ignition | Single spark plug per cylinder, Single coil |
Lubrication | wet sump |
Clutch | Single-plate |
CHASSIS
Frame | Tubular steel |
Front Suspension | Independent, unequal-length wishbones, coil springs over telescopic shock absorbers, anti-roll bar |
Rear Suspension | Independent, unequal-length wishbones, coil springs over telescopic shock absorbers, anti-roll bar |
Brakes | Discs |
Transmission | 5-speed + reverse |
Steering | rack and pinion |
Fuel Tank0 | 74 |
Front tyres | 205/70 VR 14 |
Rear tyres | 205/70 VR 14 |
BODYWORK
Type | two seater Berlinetta |
Length | 4230 mm |
Width | 1720 mm |
Height | 1120 mm |
Wheelbase | 2340 mm |
Front Track | 1460 mm |
Rear Track | 1460 mm |
Weight | 1232 kg (dry) |
PERFORMANCE
Top Speed | 215 Km/h |
Acceleration 0-100 KM/H | - |
0-400 M | - |
0-1000 M | - |
