Ferrari 400 Automatic – 1976

ENGINE

TypeFront, Longitudinal 60degree V12
Bore/Stroke81 X 78 mm
Unitary Displacement401.93 cc
Total Displacement4823.16 cc
Compression ratio8.8 : 1
Maximum power250 KW (340 hp)
Power Per Litre70 hp/l
Maximum Torque-
Valve ActutationTwin overhead camshafts per bank, two valves per cylinder
Fuel feedsix weber 38 DCOE carburettors
IgnitionSingle spark plug per cylinder, Two coils
Lubricationwet sump
ClutchTorque converter

CHASSIS

FrameTubular steel
Front SuspensionIndependent, unequal-length wishbones, coil springs over telescopic shock absorbers, anti-roll bar
Rear SuspensionSelf-levelling, Independent, unequal-length wishbones, coil springs overtelescopic shock absorbers, anti-roll bar
BrakesDiscs
Transmission3-speed + reverse
SteeringPower-assisted recirculating ball
Fuel Tank0120
Front tyres215/70 VR 15
Rear tyres215/70 VR 15

BODYWORK

Type2+2 coupe
Length4810 mm
Width1796 mm
Height1310 mm
Wheelbase2700 mm
Front Track1470 mm
Rear Track1500 mm
Weight1700 kg (dry)

PERFORMANCE

Top Speed240 Km/h
Acceleration 0-100 KM/H-
0-400 M14.9 sec
0-1000 M25.5 sec
