ENGINE
Type | front, longitudinal V12 |
Bore/Stroke | 77 X 58.8 mm |
Unitary Displacement | 273.81 cc |
Total Displacement | 3285.72 cc |
Compression ratio | 9.2 : 1 |
Maximum power | 206 KW (280 hp) at 7600 rpm |
Power Per Litre | 85 hp/l |
Valve Actutation | single overhead camshafts per bank, two valves per cylinder |
Fuel feed | three or six Weber 40 DCN/3 carburettors |
Ignition | single spark plug per cylinder, two coils |
Lubrication | wet sump |
Clutch | single-plate |
CHASSIS
Frame | Tubular steel |
Front Suspension | Independent, unequal-length wishbones, coil springs over telescopic shock absorbers, anti-roll bar |
Rear Suspension | Independent, unequal-length wishbones, coil springs over telescopic shock absorbers, anti-roll bar |
Brakes | Discs |
Transmission | 5-speed + reverse |
Steering | worm and roller |
Fuel Tank | 94 litres |
Front tyres | 195 or 205 X 14 |
Rear tyres | 195 or 205 X 14 |
BODYWORK
Type | two seater berlinetta |
Length | 4325 mm |
Width | 1725 mm |
Height | 1245 mm |
Wheelbase | 2400 mm |
Front Track | 1377 mm |
Rear Track | 1393 mm |
Weight | 1100 kg (dry) |
PERFORMANCE
Top Speed | 258 km/h |
Acceleration 0-100 KM/H | - |
0-400 M | - |
0-1000 M | - |
