Ferrari 330 LM – 1962

ENGINE

Engine Typefront, longitudinal V12
Total Displacement3967.44 cc
Unitary Displacement330.62 cc
Maximum Power287 kW (390 hp) at 7500 rpm
Bore/Stroke77 X 71 mm
Compression ratio8.8 : 1
Power Per Litre98 hp/l
Valve Actuationsingle overhead camshaft per bank, two valves per cylinder
Fuel feedsix weber 42 DCN carburettors
Ignitionsingle spark plugs per cylinder, two coils
Lubricationdry sump
Clutchmulti-plate

CHASSIS

FrameTubular steel
Front SuspensionIndependent, unequal-length wishbones, co-axial springs, telescopic shock absorbers, anti-roll bar
Rear Suspensionlive axle, semi-elliptic springs, telescopic shock absorbers
BrakesDiscs
Transmission4-speed + reverse
Steeringworm and sector
Fuel Tank140 litres
Front tyres6.00 X 15
Rear tyres7.00 X 15

BODYWORK

Typetwo seater, berlinetta
Length4360 mm
Width1675 mm
Height1245 mm
Wheelbase2420 mm
Front Track-
Rear Track-
Weight950 kg (dry)

PERFORMANCE

Top Speed280 km/h
Acceleration 0-100 KM/H-
0-400 M-
0-1000 M-
