Ferrari 250 GT 2+2 – 1960

ENGINE

Engine Typefront, longitudinal V12
Total Displacement2953.21 cc
Unitary Displacement246.10 cc
Maximum Power176 kW (240 hp) at 7000 rpm
Bore/Stroke73 X 58.8 mm
Compression ratio8.8 : 1
Power Per Litre81 hp/l
Valve Actuationsingle overhead camshaft per bank, two valves per cylinder
Fuel feedthree weber 40 DCL 6 carburettors
Ignitionsingle spark plug per cylinder, two coils
Lubricationwet sump
Clutchsingle-plate

CHASSIS

FrameTubular steel
Front SuspensionIndependent, unequal-length wishbones, coil springs, telescopic shock absorbers, anti-roll bar
Rear Suspensionlive axle, radius arms, semi elliptic springs, telescopic shock absorbers.
BrakesDrums
Transmission4-speed + overdrive + reverse
SteeringWorm and Sector
Fuel Tank100 litres
Front tyres6.50 X 15
Rear tyres6.50 X 15

BODYWORK

Type2+2 coupe
Length4700 mm
Width1710 mm
Height1340 mm
Wheelbase2600 mm
Front Track1354 mm
Rear Track1394 mm
Weight1280 kg (dry)

PERFORMANCE

Top Speed230 km/h
Acceleration 0-100 KM/H-
0-400 M-
0-1000 M-
